Woodpecker Dental Diode Laser LX16 Plus

Woodpecker Dental Diode Laser LX16 Plus

The Woodpecker Dental Diode Laser LX16 Plus is an innovative, versatile laser therapy device offering three wavelengths to address a wide range of dental applications. Designed for precise soft tissue surgery, endodontic sterilization, periodontal treatment, and other therapeutic functions, this diode laser enhances treatment outcomes while minimizing discomfort for patients.

Key Features:

• Three Wavelengths for Diverse Applications:

  • 450nm Blue Laser: Ideal for soft tissue cutting, ablation, coagulation, and incision/excision. Its absorption by hemoglobin is significantly higher than conventional lasers, allowing effective treatment with lower power and minimal thermal damage.
  • 650nm Red Laser: Used for Low-Level Laser Therapy (LLLT), also known as Photobiomodulation (PBM), which contributes to wound healing, biostimulation, and post-surgical recovery.
  • 976nm Infrared Laser: Known for its deep tissue penetration, this wavelength is effective in periodontal sterilization, endodontic disinfection, and pain management, including TMJ treatment.

• Remarkable Treatment Effect:
  The laser’s precision minimizes bleeding, swelling, and pain, promoting faster recovery. The low-power settings of the 450nm laser contribute to virtually bloodless procedures and reduced post-operative discomfort.

• Smart Interface:
  The laser features a 5-inch capacitive touch panel, providing an intuitive interface for easy control. The flat user interface design enhances interaction, making operation simple and straightforward.

• Efficient and Safe:

  • Autoclavable Fiber-optical Tips and Handpiece Sleeve: These components can be sterilized, ensuring prevention of cross-infection.
  • Large Battery Capacity: The device comes with two 11.1V 2600mAh batteries, providing up to one week of use on a single charge.

• Compact and Portable:
  Weighing 1.5kg and with a compact size (22cm x 20cm x 23cm), the LX16 Plus is portable and easy to store.

• Multiple Emission Modes:
  The device features CW (continuous wave) and Chopped modes (1Hz to 20kHz) for various surgical and therapeutic needs.

Specifications:

• Power Adapter Input: 100-240V AC, 50/60Hz, 2.5A
• Wavelength and Power:
  • 450±20nm: Max power 3W
  • 650±20nm: Max power 200mW
  • 976±20nm: Max power 5W
• Laser Classification:
  • 450nm: Class IV
  • 650nm: Class II
  • 976nm: Class IV
• Aiming Beam: 650 ± 20 nm / pmax < 5mW
• Rechargeable Battery: 11.1V/2600mAh x2 (57.7Wh)
• Charging Time: Approx. 4 hours (5 hours for first charge)
• Size: 22cm x 20cm x 23cm
• Weight: 1.5kg

Complete Accessories Included:

1. LX16 Plus Dental Diode Laser Unit
2. Handpiece Shell
3. Fiber-optical Tips (MF2-14 x2, MF2-20 x1, MF3-4 x1, MF3-9 x1, MF4-4 x1, MF4-9 x1)
4. Special Tips (DT15-TIP x1, DT20-TIP x1, DT30-TIP x1, BT8-TIP x1, Whitening-Tip x1)
5. Articulating Paper x1
6. Bending Tool x1
7. Cutting Pen x1
8. Remote Control Interlock x1
9. Goggles (3 pairs)
10. Power Adapter
11. Instruction Manual
12. Packing List
13. Warranty Card
14. Qualified Certificate

Warranty:

• Two-Year Warranty for the main unit.
• One-Year Warranty for the handpiece.
• 18-Month Warranty for the power adapter.

Benefits of the Woodpecker LX16 Plus:

• Versatility: The device's three wavelengths cater to a variety of dental procedures, including soft tissue surgeries, root canal sterilization, periodontal treatments, and TMJ pain relief.
• Patient Comfort: With reduced bleeding, minimal swelling, and pain, the LX16 Plus ensures a comfortable experience for patients, promoting faster recovery.
• Advanced Technology: The use of blue laser technology (450nm) enables highly efficient tissue cutting with minimal thermal damage, setting it apart from other dental diode lasers.
• Ease of Use: The touchscreen interface and large battery capacity make the LX16 Plus user-friendly and convenient for busy dental practices.
• Safety and Hygiene: Autoclavable components and comprehensive sterilization features ensure the highest levels of hygiene and patient safety.

The Woodpecker Dental Diode Laser LX16 Plus offers cutting-edge technology with excellent performance, making it a solid investment for dental professionals looking to provide effective, efficient, and minimally invasive treatments.
