Corix 70 Plus Wall Mounted X-Ray Dental Unit

Corix 70 Plus Wall Mounted X-Ray Dental Unit.

– Fast, Precise, and User-Friendly

The Digital-Ready Dental Intraoral X-Ray Unit offers exceptional imaging performance and reliability for your dental practice. With its powerful microprocessor, this unit ensures accurate exposure times and top-notch imaging, whether using film or a digital sensor. The system is designed for easy operation, allowing you to quickly select the desired tooth and patient size for precise radiographic results.

Key Features:

• Automatic Exposure Control: The microprocessor automatically adjusts the exposure time based on the tooth type and position, ensuring optimal image quality. It offers three patient size options and compensates for main voltage variations, providing consistent results with every use.

• Manual Override Option: If needed, you can manually override the system to make adjustments based on specific patient needs.

• LCD Control Panel: The intuitive LCD display provides clear technical information, including exposure time, voltage, and additional options for more advanced settings. It also includes an exposure counter and a digital voltmeter to monitor voltage variations.

• Focal Spot and Sharpness: The unit's 70kVp tube head is equipped with a small focal spot, low energy x-ray filter, and a beam-limiting device, ensuring outstanding sharpness and high detail in intra-oral radiography.

• Long Reach Double Positioning Arm: The long reach scissors arm offers effortless movement and flexibility, allowing you to position the unit accurately and easily. It folds compactly for storage when not in use and provides drift-free stability during use. The standard extension arm reaches up to 180.6 cm (71 1/8").

• Optional Remote Control: An optional remote x-ray button or safety double x-ray buttons can be added for added convenience and safety in your practice.

Versatile Mounting Options:

• Wall Mount: The standard wall mount comes with a 16" wall plate and is ideal for fixed positions in treatment rooms or x-ray rooms. It can also be positioned for side-by-side operatory stations.

• Single Stud Mount: Available upon request for flexible mounting options.

•

Technical Specifications:

• Rated Line Voltage: 120V ± 10% (109-132VAC), 50/60Hz
• Power Consumption: 1,050W max @ 132VAC
• Rated Tube Potential: 70kVp ± 7% (Single-phase, self-rectifying)
• Rated Tube Current: 8mA ± 15% @ 120VAC
• Exposure Time Range: 0.03 to 3.00 sec in 0.01 sec steps, plus 27 pre-set exposure times with automatic voltage compensation.
• Pre-Heating Time: Four user-selectable pre-heating options for tube loading.
• Minimum Focal Spot to Skin Distance: 200mm (8")
• Radiation Leakage: Less than 50mR/h @ 1 meter (70kVp, 8mA, 1s)
• Focal Spot: 0.8 x 0.8mm
• Total Filtration: 2mm Al eq.
• Net Weight: 63lbs (Wall mount)
• Shipping Weight: 72lbs (Wall mount)
• Shipping Dimensions: 1 box, 131 x 52 x 26 cm

Why Choose the Corix 70 Plus Wall Mounted X-Ray Dental Unit?

• Precision and Clarity: With its automatic exposure control and beam-limiting device, this unit provides clear and precise intraoral images every time.
• User-Friendly: The LCD control panel and intuitive operation make it easy to manage exposure times and adjust settings.
• Flexible Mounting Options: Whether you prefer a wall mount for fixed use or a mobile version for flexibility, this unit adapts to your practice's needs.
• Durability and Safety: Built with oversized lead shields and critical components, the unit ensures long-lasting and safe operation.

The Corix 70 Plus Wall Mounted X-Ray Dental Unit combines cutting-edge technology, ease of use, and reliable performance, making it an essential tool for modern dental practices.
